Atmospheric and Climate Sciences Products


Cloud Fraction and Cloud Cover

Cloud Fraction is derived from the cloud cover product generated using the radiance and reflectance measurements from the thermal infrared and visible channels respectively along with water vapour channel from Very High Resolution Radiometer (VHRR) onboard Indian Geo-Stationary Satellite INSAT-3D.

Derived Tropospheric Ozone

Tropospheric Ozone product is derived from OMI (Ozone Monitoring Instrument ) adnd MLS (Aura Mcrowabe Limb Sounder) instrument to study Columner topshperic ozone

Planetary Boundary Layer Height

Planetary Boundary Layer Height (PBLH) over the Indian land mass is estimated using vertical profiles of temperature and relative humidity from Cross track Infrared Sounder (CrIS) onboard Suomi-NPP, through integration of five different methods.

S.No. Product Resolution Data Availability Frequency CoverageTile Extent/Spatial Extent File Size/Download (approx.)
1 Cloud Fraction and Cloud Cover 0.10° x 0.10° , 0.25° x 0.25° 01-Sep-2008 19-Oct-2020 Half-Hourly Indian Sub-continent (-10° - 45.5° N; 44.5° E - 105.5° E) 2 - 4MB
2 Derived Tropospheric Ozone 1° x 1° 01-Jan-2010 16-Jan-2021 Daily 0° - 40° N; 60° E - 100° E 500KB
3 Planetary Boundary Layer Height (Daily, 7 Day, Monthly) 0.25° x 0.25° 01-Sep-2014 01-Jan-2021 Daily 05° - 40° N; 50° E - 110° E 200 - 300KB
